1.1.3 Universal Mount Unistrut
Loctite 243
recomended
Loctite 243
recomended
50 ft-lbs
50 ft-lbs
[68 N-m]
Complete Unistrut mount installation and turn to page 22
Minimum 1-5/8” Unistrut
Unpierced Channels (P1000
or P1001B)
12-7/8”
3/4”
