2.3 All Rapid Mounts Industrial
Motor Unit
6x
Remove six (6) screws and the bottom cover. Be careful not to damage
the electrical components with the cover removed.
Two people can lift the fan if a lift is not available.
WARNING: The fan must be lifted by the struts. Do NOT lift the fan by the drive.
