© 2018 MacroAir Technologies Toll Free: 866 668 3247 Fax: 909 890 2313 www.macroairfans.com 40
Rev. Date 040218
2.3 All Rapid Mounts Industrial
Motor Unit
Be careful of wires
30 ft-lbs
30 ft-lbs
[41 N-m]
Carefully guide the motor shaft into the extension tube.
CAUTION: Do not put force onto the building with the lift.
9/16”
Note: If purchased with the guy wire assembly, the guy wire brackets
must be installed at this stage. See page 25 for more details.
To Next Page
