2.1.3 Rapid Mount Industrial
Unistrut
50 ft-lbs
50 ft-lbs
[68 N-m]
Loctite 243
recomended
Loctite 243
recomended
12-7/8”
Complete Rapid Mount Unistrut installation and turn to page 37
Minimum 1-5/8” Unistrut
Unpierced Channels (P1000
or P1001B)
