Rev. Date 040218

This method is used to span components of a

building structure. Attachment points to the

building structure can vary greatly, so we

recommend contacting Unistrut so they can

recommend the best method for attaching the

Unistrut (www.unistrut.us).

If the spanning distance is greater than 8 feet,

please consult a Structural Engineer. Please

refer to page 4 for the maximum torque and

weight values.

NOTE: Mounting to C- and Z-purlins requires Unistrut span

mounting. Mounting to trusses under three (3) inches in width

requires two or more trusses to be linked with Unistrut.

1.1.3 Universal Mount Unistrut
