© 2018 MacroAir Technologies Toll Free: 866 668 3247 Fax: 909 890 2313 www.macroairfans.com 49
Rev. Date 040218
4.1 Drive Installation
Ensure ground wire is
properly attached
CAUTION: RISK OF ELECTRIC SHOCK. The bus capacitors discharge
to a level below 50V DC in 1 minute.
Note: Model numbers ending with an “H” are high voltage while model
numbers ending with an “L” are low voltage.
High Voltage Drive
WARNING: POWER ABOVE 255VAC WILL DESTROY A LOW VOLTAGE DRIVE
Low Voltage Drive
To Next Page
