Rev. Date 040218

Use the two holes closest to

the center line of the glulam.

3/16" safety cable clearance

Holes can be oversized

for leveling the mount

1/2" bolt clearance

75 ft lbs

75 ft-lbs

[102 N-m]

The bracket can be below the bottom

of the glulam if necessary but

is not recomended if it is avoidable.

This method is recommended for Glulams or wood beams 5-1/8” or

wider. For narrower beams, span across two or more beams using the

Unistrut mounting method.

2.1.2 Rapid Mount Industrial

Glulam
