© 2018 MacroAir Technologies Toll Free: 866 668 3247 Fax: 909 890 2313 www.macroairfans.com 41
Rev. Date 040218
Ensure the fan is level
30 ft-lbs
Tighten only the
middle and bottom
bolts on both sides
30 ft-lbs
[41 N-m]
Tighten only the
middle and bottom
bolts on both sides
2.3 All Rapid Mounts Industrial
Motor Unit
Do not bend rubber bootDo not bend rubber boot
WARNING: Do not put too much tension on the safety cable. This will
deform the rubber boot and hinder the proper cooling of the motor.
Rapid Mount Industrial I-Beam safety cable starts on page 42
Rapid Mount Industrial Glulam safety cable starts on page 43
Rapid Mount Industrial Unistrut safety cable starts on page 44
9/16”
To Next Page
