TRANSPORT
Loading with a crane
Operating manual MT 32 / 36 125
Loading with a crane
The MT has sling points for use during crane transport.
Two sling eyes are located behind the driver's cab;
the third one is the tow hitch at the rear.
To perform loading tasks, you have to unhook the pneu-
matic spring at the service door.
WARNING!
Danger of being crushed!
When the pneumatic spring is unhooked, there is dan-
ger of the service door falling closed and injuring you.
X Always wear personal protective equipment when
attaching hoisting gear.
Fig. 1: Unhooking the pneumatic spring
1 Service door
2 Pin with fastener
3 Pneumatic spring
Unhooking the pneumatic spring
X Open the service door 1.
X Unclip the fastener of the pin 2.
X Pull the pin 2 out of the fork head of the pneumatic spring 3.
X Remove the pneumatic spring 3.
X Re-install it in reverse order.
Fig. 2: Front sling points
1 Front sling points
2 Service door
