CONTROL ELEMENTS
Practical features
88 Operating manual MT 32 / 36
Shut-off cocks, brake spiral hoses <optional>
With the shut-off cocks, you close off the air connections of the
brake spiral hoses. You thereby avoid loss of air in the
compressed air system, caused by uncoupling the brake spiral
hoses from the air connections on the connection console.
Fig. 82: Shut-off cocks (shown closed)
1 Closed
2 Opened
3 Brake line (yellow)
4 Supply line (red)
