Test Equipment 2-17

10.0 Test Equipment

Table 2-3 lists test equipment required to service the Mag One by Motorola Radios and other two-way

radios.

11.0 Programming Cable (PMDN4043_R)

Table 2-3 Recommended Test Equipment

Motorola

Part No.

Description Characteristics Application

R2600 Communication

Analyzer

Frequency/deviation meter and signal

generator for wide-range troubleshooting

and alignment

R1038 Handheld Multimeter AC/DC Voltage and current measure-

ments

S1339A/220 RF Millivolt Meter

220V

100mv to 3VRF

100kHz to 1.2GHz

RF Level Measurements

Figure 2-15 Programming Cable Schematic
