2-16 Service Aid
9.0 Service Aid
Table 2-2 lists service aids recommended for working on the Mag One by Motorola Radios. While all
of these items are available from Motorola, most are standard shop equipment items, and any
equivalent item capable of the same performance may be substituted for the item listed.
Table 2-2 Service Aids
Motorola Part
No.
Description Application
PMDN4038_R Chassis Opener To disassemble the radio
PMDN4039_R Crab Eye Nut Opener To fasten or remove crab-eye nut.
PMDN4040_R Test Box Enables connection to the audio/accessory jack.
PMDN4041_R RF Adapter Adapts radio antenna port to BNC cabling of test
equipment.
PMDN4043_R Programming/Test
Cable
Connects radio to Computer.
PMDN4060_R Cloning Cable Allows a radio to be duplicated from a master radio by
transferring programmed data from the master radio
to the other.
PMDN4042_R Battery Eliminator Interconnects radio to power supply (red-and-black
power cable included).
PMDN4054_R Antenna Ground Plate To improve grounding while conducting tuning and
measurement.
PMDN4044_R T-Head Ceramic
Tuning Tool
To tune the variable resistor for audio and sub-audio
modulation adjustment; tuning points accessible via
battery-chassis area.
PMDN4026_R Flat Ceramic Tuning
Tool (1.8mm)
To tune the variable resistor for audio and sub-audio
modulation adjustment; requires disassembly of PCB
from chassis to get access to tuning point.
PMDN4053_R Flat Ceramic Tuning
Tool (0.9mm)
– Phillips Head
Screwdriver
To remove M2 and M2.6 Phillips screws.
– Flat Head Screwdriver To remove speaker from speaker felt.
– Tweezers To remove smaller components i.e. latch pad and
speaker connector.
TT907A National
Service Technical
Guide
Repairing Leadless
Component
Assemblies
Guide on how to successfully remove and replace
surface mount devices.
