Mechanical View and Parts List 2-15

33 PMDN4029_R Tuning Hole Sticker (Big) 2

34 PMDN4047_R Motorola Caution Label 1

35 PMDN4030_R Dust Cover 1

36 PMDN4031_R Audio Jack 1

37 Audio Bracket 1

38 PMDN4032_R Audio Jack Seal 1

39 PMDN4033_R Microphone 1

40 Microphone Boot 1

41 PMDN4034_R Antenna Bracket 1

42 PMDN4035_R PTT Tact Switch 1

43 PMDN4056_R Programming Button Tact Switch 2

44 PMDN4036_R Speaker Connector 1

45 PMDN4037_R Pogo Pin Seal 1

46 Pogo Pin Housing 1

47 Pogo Pin 2

48 PMAD4051_R Mag One™ 150 – 174 MHz Antenna 1

PMAE4020_R Mag One™ 450 – 470 MHz Antenna 1

49 PMLN4743_ Mag One™ Spring Belt Clip 1

50 PMNN4071_R Mag One™ NiMH Battery 1200mAh 1

PMNN4075_R Mag One™ LiIon Battery 1500mAh 1

51 PMDN4058_R PCB-Chassis Tape for PMUD2086A_,

PMUE2385A_

PCB-Chassis Tape for PMUD2086B_ 2

PCB-Chassis Tape for PMUE2385B_ 3

52 PMDN4025_R O-Ring 1

53 PMDN4027_R PCB Screw 11

Items are also available as PMDN4051_R.

*Non-EPP compliant boards must be used with PMDN4011_R and PMDN4024_R.

†

EPP compliant boards must be used with PMDN4067_R and PMDN4068_R.

Table 2-1 Parts List

Reference

Part No Part Name Qty
