2-14 Mechanical View and Parts List
7 PMDN4010_R PTT Bezel 1
8
§
PMDN4011_R Speaker & Cable (non-EPP) 1
PMDN4067_R Speaker & Cable (EPP) 1
9
§
PMDN4012_R Speaker Bracket 1
10
§
Speaker Bracket Screw 1
11
§
PMDN4013_R Speaker Poron Pad 1
12
§
PMDN4046_R Speaker Felt 1
13 PMDN4014_R Volume Knob 1
14 Volume Knob D-Clip (D: 6.0) 1
15 PMDN4015_R Channel Knob 1
16 Channel Knob D-Clip (D: 3.5) 1
17 PMDN4016_R Volume Potentiometer 1
18 Crab-Eye Knob Nut 1
19 PMDN4017_R Channel Potentiometer 1
20 Crab-Eye Knob Nut 1
21 PMDN4018_R Channel & Volume Top Seal 1
22 PMDN4021_R Top Escutcheon 8 Channels 1
PMDN4020_R Top Escutcheon 16 Channels 1
23 Top Adhesive 1
24 PMDN4022_R Battery Latch 1
25 Battery Latch Shaft 1
26 Battery Latch Tape 1
27 PMDD4001_R* 150 – 174 MHz 5W PC Board (non-EPP) 1
PMDD4005_R
†
150 – 174 MHz 5W PC Board (EPP) 1
PMDE4001_R* 450 – 470 MHz 4W PC Board (non-EPP) 1
PMDE4005_R
†
450 – 470 MHz 4W PC Board (EPP) 1
28 PMDN4068_R Radio Chassis (EPP) 1
PMDN4024_R Radio Chassis (non-EPP) 1
29 Thermal Pad 1
30 PTT Insulation Tape 1
31 Insulation Tape 2
32 PMDN4028_R Tuning Hole Sticker (Small) 2
Table 2-1 Parts List
Reference
No
Part No Part Name Qty
