TS over UDP/RTP
Name: specify a name for current task to facilitate server management,
which will be displayed in server list.
■
Stream: choose to stream main or sub stream, which can be customized in
Encoding Parameters tab.
■
Address: specify the destination address.
■
Port: specify the stream port. The value ranges from 1 to 65535.
■
Network: The device scans for the available network according to the
connection priority and connect to it for streaming. If the current network is
disconnected, the unit automatically re-scans according to the priority.
By default, the network connection priority is: Mobile Broadband > Ethernet
> Wi-Fi.
Plug a USB modem into your encoder while using mobile network to
stream.
■
Save: save current configuration.
■
The encoder can stream up to 6 TS sessions simultaneously. The
recommended total bitrates for the streams is below 24Mbps for a wired
network connection, and 16Mbps for a wireless network connection.
■
