Magic Chef MCSBRG24W Installation Manual

18
24” Burner and Orifice Characteristic Table
Refer to the following chart for correct gas orifice spud placement�
IMPORTANT: Save the orifices removed from the appliance for future use.
Burner Position
Orifice Gas Pressure Rate
Diam� (mm) Type [i�w�c] [BTU/h]
Auxiliary Front R
0�9 NG 4”
3500
0�56
LP (Propane) 10”
3500
Semi-Rapid
Rear L & R
1�18
NG 4”
6000
0�72
LP (Propane) 10”
6000
Triple Front L
1.8
NG 4”
13000
1.08
LP (Propane) 10”
13000
Broil
NG 4”
5800
LP (Propane) 10”
5800
Oven
1�4
NG 4”
8500
.72
LP (Propane) 10”
8500
1.16
�72
