Magnetek DSD 412 - Figure 10: Drive Brake Control Feature

INTERCONNECT DRAWING
33
Figure 10: Drive Brake Control Feature
83
K6
82+24 VDC
K6x, 24VDC
(LIFT & HOLD)
R/C
R/C
115 VAC
CONTROL
POWER
K3x
K6x
BRAKE
PICK
BRAKE
LIFT
ELEVATOR BRAKE COIL
R-HOLD BRAKE
PICK
BRAKE VAC
SUPPLY SOURCE
BRAKE
LIFT
CONNECTIONS FOR
ELEVATOR BRAKE CONTROL
RECTIFIER
AS REQ'D
BRAKE
LIFT
RELAY COILS 24VDC
LESS THAN 100 MA
36
37
K3
1N4002
K3x, 24VDC
(BRAKE PICK)
DSD 412
MAIN PCB
57 or 80COMM
