DISPLAY MONITOR FUNCTIONS
65
Function # 616
Speed Error
Units: %
This displays the difference between the
speed reference and speed feedback.
Function # 617
AC Line Frequency
Units: Hz
This display is the measured frequency of
the 3-phase AC line.
Function # 618
Heatsink Temp
Units: C°
This display is the measured heat sink
temperature of the drive in C°.
Function # 619
AC Line Voltage
Units: Volts rms Line-Line
This display is the measured 3-phase AC
input line-line voltage.
Function # 620
F413 Tracking level
Units: PU
This is the difference between the Field
Current reference and the Feedback. F413
warning will result if higher than F192 for 5
seconds.
Function # 621
Serial Communication Control Enabled
Units: LOGIC
This logic will be ON if RS422 (or RS232)
control communications is enabled for drive
control. Does not include use of PCDU.
Functions # 688-699
The following read-only values identify the
drive hardware set up and control software
stored in E-PROMs U13, U14, U39, & U40.
FUNCTION
#
DESCR
.
VALUE
688
CUBE I.D.
Table 9
689
FIELD
RANGE
Table 10
690 U13/U14
“97SAXXX”
404
691 PCU
RELEASE
692 DAY
693 MONTH
695 YEAR
696 BETA “P”
697 U39/U40
“97SAXXX”
407
698 DCU -
REVISION
699 CUSTOMER
VERSION
I.D.
9
