IMPULSE®•G+ & VG+ Series 4 Instruction Manual – February 2017
6-15
OPE19
Stp-Mthd & Ctrl
Incompatible Setting of Stopping
Method and Control Method.
1. Satisfy B03-03 > 6 and A01-02 < 1.
OPE20
EPLS Setting
Electronic Programmable Limit
Switch Setting Error.
1. Check if C03-14 = 0, 2 or 4:
C03-19 > C03-18 > C03-17 > C03-16
1. Check if C03-14 = 1 or 3:
C03-19 < C03-18 < C03-17 < C03-16
OPE21
2nd Chan Missing
Option Card PG-X3 is missing when
C11-08 is Enabled.
1. Install correct option card.
OPE22
Ctrl & Motion
Incompatible Setting of Motion and
Control Method.
1. Satisfy A01-02 < 1 and A01-03 > 2.
OPE23
Hook Height Home
Hook Height Home MFDI Setting
Error. Hook Height Home is set to UL2
N.O., LL2 N.O., or UL3 N.O., but no
MFDI is programmed for the
corresponding function.
1. Check C03-14 settings.
2. Check H01-xx settings.
OPE24
Slack Cable
Slack Cable. Incorrect setup. 1. Satisfy condition C11-04 < C11-06
and
C11-05 < C11-07.
OPE28
Dual Brake MFDO
Dual Brake MFDO. MFDO
programmed to 0AH, but no output
programmed to 00H. Must have 00H
and 0AH programmed.
1. Check that one MFDO is
programmed to 00H.
2. Check that one MFDO is
programmed to 0AH.
3. Set C08-33 to Disabled.
Code Error Name/Description Corrective Action
