inteleSmart2 Instruction Manual
June 2016
Page 16 of 49
4. WIRING
4.1 ALARMS AND HORNS
Make sure that the installation includes the proper alarms, horns, indicator lights, and their associated
controls as required by local and governmental regulations.
4.2 POWER
The inteleSmart2 can be powered from 24/42/48VAC, 48/115/230VAC, or 6-36VDC. The unit needs to
be configured based upon the type of input power that is being used.
4.2.1 DC Power
To power the unit with 6-36VDC, the input power needs to be connected to J29. Pin 1 is VCC and pin 2
is ground.
.
4.2.2 AC Power
There are two different AC power transformers that can be populated within the receiver. One
transformer supports 48/115/230VAC, 50/60Hz and another transformer supports 24/42/48VAC, 50/60Hz.
Input voltage ranges are configured by changing the position of the wire jumper in J7. See Table 1 for the
jumper settings for the 48/115/230VAC power supply.
Voltage Range Position 1 Position 2
48VAC
36-60VAC
3 4
115VAC
85-150VAC (Default)
2 4
230VAC
190-265VAC
1 4
Table 1: 48/115/230VAC Transformer Input Power Wiring
Table 2 has the jumper settings for when the 24/42/48VAC power supply is used.
Voltage Range Position 1 Position 2
24VAC
18-36VAC (Default)
3 4
42VAC
36-48VAC
2 4
48VAC
36-60VAC
1 4
Table 2: 24/42/48VAC Input Power Wiring
NOTE: These jumper settings apply whether the AC signal is operating at 50Hz or 60Hz.
1
J29
