Refer to the Model 706 Installation and Operating Manual
Bulletin 57-606 for additional information on password
protection.
For an SIS system, it is required that, after configuration of
the system is complete, a password is utilized to prevent
inadvertent changes to the device.
6.6 Site Acceptance Testing
To ensure proper operation after installation and configura-
tion, a site acceptance test should be completed. This
procedure is identical to the Proof Test Procedure described
in Section 7.1.4.
6.7 Recording Results
Results of Site Acceptance Testing must be recorded for
future reference.
6.8 Maintenance
With no moving parts to wear out or lose tolerance, routine
maintenance is not required.
6.8.1 Diagnostics and Response Times
Continuous internal diagnostics are present within the
Enhanced ECLIPSE Model 706 transmitter. In the event a
Fault is detected, a message will appear on the LCD and the
output current will be driven to 3.6 mA or 22mA depending
on how the FAULT parameter is configured.
A) Start-up Time:
a. From application of power to normal operat-
ing mode: 6 seconds
b. From application of power to Fault mode:
29 seconds or less (Assuming a Fault is present
upon start-up)
B) Diagnostic Test Interval: 15 seconds
a. This is defined as the time from the normal
operating mode to the Fault mode upon the
occurrence of a fault.
C) Safety Function Response Time:
3 seconds (with Damping=0)
6.8.2 Troubleshooting
Report all failures to the MAGNETROL Technical Support
Department.
Refer to the Model 706 Installation and Operating Manual
Bulletin 57-606 for troubleshooting device errors.
8
57-657 SIL Certified Safety Manual for ECLIPSE Model 706
