T R A N S M I T T E R S P E C I F I C A T I O N S
F U N C T I O N A L / P H Y S I C A L
10
System Design
Measurement Principle Pulse burst radar 6 GHz
I
nput
Measured Variable Level, determined by the time-of-flight of radar pulse reflections
Span 0.5 to 130 feet (0.2 to 40 meters)
O
utput
Type 4 to 20 mA with HART: 3.8 mA to 20.5 mA useable (per NAMUR NE43)
F
OUNDATION fieldbus
™
: H1 (ITK Ver. 6.1.2)
R
esolution Analog .003 mA
Digital Display 1 mm
Loop Resistance 591 ohms @ 24 VDC and 22 mA
Diagnostic Alarm Selectable: 3.6 mA, 22 mA (meets requirements of NAMUR NE 43), or HOLD last output
Diagnostic Indication Meets requirements of NAMUR NE107
Damping Adjustable 0-10
User Interface
Keypad 4-button menu-driven data entry
Display Graphic Liquid Crystal Display
Digital Communication HART Version 7–with Field Communicator, F
OUNDATION fieldbus
™,
AMS, or FDT
DTM (PACTware
™
), EDDL
Menu Languages Transmitter LCD: English, French, German, Spanish, Russian
HART DD: English, French, German, Spanish, Russian, Chinese, Portuguese
F
OUNDATION fieldbus Host System: English
Power (Measured at instrument terminals) HART: General Purpose (Weather proof)/Intrinsically Safe/Explosion-proof:
11 VDC minimum under certain conditions (refer to I/O Manual 58-602)
F
OUNDATION fieldbus
™
: 9 to 17.5 VDC
FISCO, FNICO, Explosion Proof, General Purpose and Weather Proof
Housing
Material IP67/die-cast aluminum A413 (<0.6% copper); optional stainless steel
Net/Gross Weight Aluminum: 4.5 lbs. (2.0 kg)
Stainless Steel: 10.0 lbs. (4.50 kg)
Overall Dimensions H 8.34" (212 mm) × W 4.03" (102 mm) × D 7.56" (192 mm)
Cable Entry
1
⁄2" NPT or M20
SIL 2 Hardware (Safety Integrity Level) Safe Failure Fraction = 92.7% (HART only)
Functional Safety to SIL 2 as 1oo1 in accordance with IEC 61508
(Full FMEDA report available upon request)
Operating Temperature -40° to +175° F (-40° to +80° C); LCD viewable -5° to +160° F (-20° to +70° C)
Storage Temperature -50° to +185° F (-45° to +85° C)
Humidity 0–99%, non-condensing
Electromagnetic Compatibility Meets CE requirement (EN 61326) and NAMUR NE 21
NOTE: Antennas must be used in metallic or concrete vessel or stillwell to
maintain CE noise immunity
Surge Protection Meets CE EN 61326 (1000V)
Shock/Vibration ANSI/ISA-S71.03 Class SA1 (Shock); ANSI/ISA-S71.03 Class VC2 (Vibration)
E N V I R O N M E N T
