Magstim Rapid²
Operating Manual
© The Magstim Company Limited 9 MOP03-EN-03
3.1.2.10 Cooling Fan Outlet (10)
With the Magstim Rapid² system turned on, air is drawn through slots at the bottom of the instrument
and expelled through the fan outlet. There should be no obstructions placed closer than 50mm to the
fan outlet.
3.1.2.11 HV Power Entry Socket (11)
The HV cable is connected to this connector to interconnect the high voltage power between the
mainframe and the PSU.
Note: High voltage can be present on this connector.
3.1.2.12 Earth Strap (12)
The Rapid
2
system must only be used when fitted with the supplied earth straps, this is to maintain the
system’s compliance with EN 60601-1-2 regarding Electro-Magnetic emissions. The strap is fitted
between the stimulator and the PSU.
3.1.2.13 Mains input to PSU* (13)
Mains input port on the Standard Rapid² PSU and Super Rapid² PSU.
