MAGSTIM RAPID2 - A3. Base System Error Codes

Magstim Rapid²
Operating Manual
© The Magstim Company Limited 56 MOP03-EN-03
A3. Error Codes produced by base system.
Error Codes
Description
E61
Power fail
E62
Stack underflow
E63
Stack overflow
E64
RTS overrun
E65
WD Timeout
E66
Unexpected reset
E67
Bad checksum
E68
SYS debug error
E70
Coil under temperature
E71
Coil max difference
E72
Stack over temperature
E73
Stack under temperature
E74
Stack max difference
E75
HVCAP over temperature
E76
HV Transformer over temperature
E77
Charge threshold failure
E78
VREF check failure
E79
HVCAP voltage comparison failure
E80
Charging fault
E81
HV over voltage
E82
Invalid system configuration
E83
Stop line fault
E84
Base coil stop line fault
E85
UI stop line fault
E86
Dump system fault
E87
Invalid coil category for current system configuration.
E88
Invalid NVRAM Checksum.
E89
Faulty charging relay detected
E90
Base arm LED drive failure
E91
External PSU Fault
E92
Base over temperature
E93
Snubber board over temperature
E94
Base under temperature
E95
HV CAP under temperature
E96
Snubber board under temperature
E97
Ambient over temperature
E98
System failed to produce protocol
For diagnosis, contact The Magstim Company Limited service department (see Section 7.2 for contact
details).
