6 - Magnetic Stripe Card Data Sent from Device to Host (MSR Only | Keypad Entry Only)
eDynamo| Secure Card Reader Authenticator | Programmer’s Manual (COMMANDS)
Page 48 of 245 (D998200115-17)
Table 6-4 - MagnePrint Status Example
Nybble
Hex Value
MP Status Bit
Value
Usage
1
A
7
1
Product Revision/Mode
6
0
Product Revision/Mode
5
1
Product Revision/Mode
4
0
Product Revision/Mode
2
1
3
0
Product Revision/Mode
2
0
Product Revision/Mode
1
0
Product Revision/Mode
0
1
MagnePrint capable
3
0
15
0
Product Revision/Mode
14
0
Product Revision/Mode
13
0
Product Revision/Mode
12
0
Product Revision/Mode
4
5
11
0
Product Revision/Mode
10
1
Product Revision/Mode
9
0
Product Revision/Mode
8
1
Product Revision/Mode
5
0
23
0
Reserved
22
0
Reserved
21
0
Direction
20
0
Reserved
6
0
19
0
Too Fast
18
0
Too Slow
17
0
Reserved for noise measurement
16
0
Reserved
7
0
31
0
Reserved
30
0
Reserved
29
0
Reserved
28
0
Reserved
8
0
27
0
Reserved
26
0
Reserved
25
0
Reserved
24
0
Reserved
