8.3.13 Command 0x46 - Send Command to Bluetooth LE Controller (Bluetooth LE Only)
This command sends commands to the device’s Bluetooth LE controller, which has its own command set
used to control Bluetooth LE-specific aspects of the device. The valid command identifiers and data are
defined in the following subsections.
Table 8-21 - Request Data for Command 0x46 - Send Command to Bluetooth LE Controller (Bluetooth LE
Only)
Offset
Field Name
Description
0
Data type
Always set to 1 (control data).
1
Message type
Always set to 0 (request).
2
Bluetooth LE command
identifier
The identifier of the Bluetooth LE command.
3..n
Bluetooth LE command request
data
The data associated with the Bluetooth LE command
request.
Table 8-22 - Response Data for Command 0x46 - Send Command to Bluetooth LE Controller (Bluetooth LE
Only)
Offset
Field Name
Description
0
Data type
Always 1 (control data).
1
Message type
Always 1 (response).
2
Bluetooth LE result
code
A code that indicates the result of the Bluetooth LE command. Valid
values for this code are 0 for success, 1 for failure and 2 for bad
parameter.
3..n
Bluetooth LE
command response
data
The data associated with the Bluetooth LE command response.
Result codes:
0x00 = Success
0x01 = Fail (timed out waiting for a response)
Example Request (Hex)
Cmd Num
Data Len
Data
46
06
01 00 02 01 02 03
(Send Echo command)
Example Response (Hex)
Result Code
Data Len
Data
00
06
01 01 00 01 02 03
