2
Description
Pos: 32 /Techn ische Dokument ation/Alle Ger äte/Übersc hriften/ Überschrifte n 1.1/A/Übersc hrift 1.1: Allgem eines @ 6\mod_1182865005781_75.docx @ 97736 @ 2 @ 1
2.1
General Information
Pos: 33 / Techn ische Dokument ation/ Papier korb/H ebetech nik/Inha lt: Bes chreibu ng A llgemein es RGE @ 17\m od_1250243858131_75.docx @ 428020 @ @ 1
The mobile column lifts of the RGE series are produced as wheel engaging or universal lifts.
Depending on the version, the lift system consists of 2 or 4 columns and can be expanded to 6
columns in the standard version.
The lift can be expanded up to 12 columns when using a special power supply unit.
All components are easily accessible under the lifted vehicle due to a generous maximum lifting
height of 1750 mm.
The lift is a mobile unit whereby the columns can be substituted with stands when vehicles are to
be worked on for a longer period of time. The lifting columns are free to be used on other vehicles.
Pos: 34 /Techn ische Dokument ation/Alle Ger äte/Übersc hriften/ Überschrifte n 1.1/L/Über schrift 1.1: Lärmem ission @ 13\mod_1236767272078_75.docx @ 354579 @ 2 @ 1
2.2
Noise Emission
Pos: 35 / Techn ische Dokument ation/ Hebetech nik/ - Arch iv -/ 00 Heb etechni k - Alle/ Inh alte/ I nha lt: S cha lldr uc kpe gel < 70 dB( A) @ 1 4\mod_1241593887290_75.docx @ 371013 @ @ 1
The sound pressure level is lower than 70 dB(A) in the working area of the operator.
Pos: 36 /Techn ische Dokument ation/Alle Ger äte/Übersc hriften/ Überschrifte n 1.1/T/Über schrift 1.1: Tech nische Daten @ 7\mod_1184075526343_75.docx @ 99711 @ 2 @ 1
2.3
Specifications
Pos: 37 / Techn ische Dokument ation/ Hebetech nik/ COLUMN LIF T/4 908 01 RGE / BA/I nha lt: 490 8 Tec hn isc he Da te n (Ta be lle) @ 1 8\mod_1256046112218_75.docx @ 480360 @ @ 1
RGE
RGE GPGU
RGE T
Load capacity per column 7500 kg 7500 kg 5000 kg
Full travel 1750 mm 1750 mm 1750 mm
Raising / Lowering time 113 s 113 s 113 s
Raising speed 0.92 m/min 0.92 m/min 0.92 m/min
Tyre diameter 900…1250 mm --- 600…2000 mm
Motor power 1.5 kW 1.5 kW 1.5 kW
System of protection IP 54 IP 54 IP 54
Supply voltage 3~ 380/220 V; 50 Hz 3~ 400 V; 50 Hz 3~ 400 V; 50 Hz
Net weight per column 452 kg 502 kg 542 kg
Surface load 0.5 N/mm
2
0.5 N/mm
2
0.5 N/mm
2
Pos: 38 / Techn ische Dokument ation/ Hebetech nik/ - Arch iv -/ 00 Heb etechni k - Alle/In halte/ Inf o!/In halt : Inf o - Betr iebswar mer Z ustand / Tech n. Änder ungen H BZ @ 6\mod_1177427042703_75.docx @ 90160 @ @ 1
The properties indicated apply to lifts running at operating temperature.
Specifications are subject to change without notice.
