► STEERING
Ensure that the steering wheel does not have excessive free play.
► BRAKE
Ensure that the left and right brake rods are adjusted correctly so they operate simultaneously.
► ELECTRICAL
Check the operation of all gauges, switches, horn, lights and indicators.
► INSTALLING LOADER
1. Loose the plugs of the P, C, and T port in the hydraulic valve.
2.Connect the P port of the loader control valve to the line on the tractor marked P
3.Connect the T port on the loader control valve to the line on the tractor marked T.
4.Connect the remaining line from the control valve to the line on the tractor marked C.
5. Turn loader select cock to CW direction.
►
DETACHING THE LOADER (LOADER VALVE OR LOADER CONNECTING PORT)
1.Detach the hydraulic hoses of the loader.
2.Assemble the plugs of the P, C, and T port.
3 Turn loader select cock to CCW direction.
C
T
CCW
(W/O loder)
CW
(W loder)
50
Loader select cock
When is loader installed, the turn clock-wise
valve cock. Also when loader is not installed,
turn counter clock-wise valve cock
