Mahindra e Max 22 HSTs User Manual

► DESCRIPTION
■ General Construction
The transmission case, engine and front axle support are bolted together to form a rigid unit.
■ Front Axle & Wheels
The 4WD front axle is a cente
r
-
p
ivot
,
reverse Eliot t
yp
e.
p, yp
The front wheel drive mechanism is incorporated as a part of the axle.
The front wheel drive power is taken from the rear transmission and transmitted to the differential in the
front axle where the power is divided into right and left and to the respective final cases.
In the final cases, the transmitted revolution is reduced by the level gears to drive the front wheel.
The 4WD mechanism with level gears provides wider steering and greater durability.
■ Engine
The tractors are fitte
d
with fuel efficient engines with 3 cylinders manufacture
d
b
y Daedong.
■ Transmission with HST (Hydrostatic Transmission)
The Tractor is fitted with a 2 Range HST.
Speed range by a HIGH-LOW selector lever.
The tractor has two pedals for forward/reverse control.
Tractors with Independent Power Take Off are fitted with an electro-hydraulic Clutch Assy.
Th
e
R
ea
r PT
O
a
n
d
Mi
d
PT
O
ca
n
be
ope
r
ated
toget
h
e
r
o
r
sepa
r
ate
l
y
by
a
l
eve
r
.
e ea O a d d O ca be ope ated toget e o sepa ate y by a eve .
■ Brakes
Mahindra tractors are provided with disc brakes operated by foot pedal.
A parking brake lever is fitted for parking.
■ Rear axle & Wheels
This is mounted on ball bearings and is enclosed in removable housing which are bolted to the
transmission case.
The rim & Disc fitted with Rear tires are bolted to the outer flange of the rear axle.
■ Hydraulic System & Linkages.
Mahindra Tractors are fitted with Live (i.e. system is in operation) independent, Systems.
Three point Linkages can be used for category 1(N) type of implements.
■ Steering
Steering consists of a Hydrostatic Power Steering system, which has a hydraulic cylinder and single type
hydraulic
pump
hydraulic
pump
■ Electrical System
A 12 Volt Battery is used to activate the engine through the starter motor and the electrical system
comprising the horn, head lamp, turn signal lamp, tacho-meter, hour meter, brake lamp, gauge lamp,
hazard lamp and general or alternator, fuse box which also from part of the electrical system.
6
