Mahindra e Max 22 HSTs User Manual

MODEL e Max 22 HST s / e Max 25 HST s
Clutch Main Dry single disc, mechanic
Transmission
Hydraulic + Mechanical
H/L with constant-mesh
Drive Train
MFWD (4WD) Standard
Differential lock Bevel gears with diff-Lock
Brake
Wet Disc, Foot operated, independent with provision of inter lock for simultaneous
operation.
Inner dia. 77 mm(3.03 in.)
Outer dia. 123mm(4.84 in.)
Number of lining 4 each side
Total brake thickness 6.4mm(0.27 in.)
PTO
Type Independent(Transmission PTO)
Rear
Shaft 6 Splines, 35 mm(1⅜ in.)
Speed
540 rpm ＠ 2,893 rpm
Shaft 15 S
p
lines
,
25.4 mm
(
1 in.
)
Mid
p
,()
Speed
2,000 rpm ＠ 2,875 rpm
Hydraulic
Steering Hydrostatic
Pump capacity 25.7 lpm (6.79 US gpm)
Main Relief pressure 2205 psi (15.2 Mpa)
Steering Relief Pressure 1566 psi (10.8 Mpa)
3point linkage Category
Cat 1(N)
Hitch
3point
linkage
Category
Cat
.
1(N)
Lift capacity
600 kg (1323 lb) ＠ hitch
Dimensions
Overall length 2553 mm(100.5 in.)
Overall width 1164 mm(45.8 in.)
Overall Height 2320 mm(91.3 in.)
Wheel base 1460 mm(57.5 in.)
Min. Ground Clearance 240 mm(9.4 in.)
Weight 730 kg (1610 lb)
75
