21 Lifting and Supporting
21 LIFTING AND SUPPORTING
Place the ROXOR on a flat, non-slippery surface. For hydraulic jack
lifting, place the hydraulic jack under the center of the axle only.
Once lifted, support the ROXOR with suitable jack stands positioned
under the right and left frame rails. If lifting just the front, or just the
back, be sure to block the opposite wheels using rocks, logs or wheel
chocks.
For hoist lifting, only use the two front locations (see Figure 6) and
the two rear locations (see Figure 7) shown here.
Verify the unit is stable on the hoist before raising all
the way up and going underneath it to help prevent an accident res-
ulting in severe injury or death.
Figure 6. Front Lifting Location
Figure 7. Rear Lifting Location
© 2018 Mahindra Vehicle Sales and Service, Inc. All Rights Reserved. 51
