23 Maintenance Procedures
23.17 Replace Transfer Case Oil
Maintenance Interval – Replace 300 hours, 36 months, 9,000 miles
(15,000 Km)
Capacity – 1.7 Quarts (1.6 Liters)
Fluid Spec. – GL-4 SAE 80W90
1. Clean the oil level plug, drain plug and surrounding area.
2. Place a container to collect oil, under the transfer case.
3. Remove the drain plug.
4. Remove the oil level plug. (see Figure 25)
5. Let the oil drain out.
6. Tighten the drain plug.
7. Fill new oil through oil level plug using a funnel until it begins to
drip out.
8. Tighten the oil level plug.
Figure 25. Transfer Drain Plug
72 © 2018 Mahindra Vehicle Sales and Service, Inc. All Rights Reserved.
