26 Specifications
26 SPECIFICATIONS
26.1 Fluid Specifications and Quantities
Fluid Type FluidSpecification Fluid Quantity
Brake Fluid SAE J1703 Dot 3 .95 Quarts (.90 Liters)
Engine Coolant JIS K2234/ASTM D3306 8.5 Quarts (8.0Liters)
Engine Oil API CJ-4 5W/40
(Full Synthetic)
7.4 Quarts (7.0 Liters)
Front & Rear
Axle Gear Lube
GL-5 SAE 80W-90 1.9 Quarts (1.8 Liters)
Leaf Spring Pivots NLGI-3 (Multipurpose Lith-
ium Grease)
As Required
Power Steering Fluid DEXRON III/Mercon .63 Quarts (.60 Liters)
Shift Linkage Fluoropolymer Penetrating
Lubricant
or PTFE Lubricant
As Needed
Transfer Case Fluid GL-4 SAE 80W90 1.7 Quarts (1.6 Liters)
Transmission Fluid GL-4 SAE 80W90 2.1 Quarts (2.0 Liters)
U-Joints NLGI-2 (EP2 Lithium Soap
Grease)
As Needed
WheelBearings NLGI-2 (Lithium Complex
Grease)
As Needed
26.2 Vehicle Specifications
Dimensions and Capacities
Wheelbase 96" (2.44 m)
DryWeight 3000 lbs. (1360 kg)
Length 148"(3.76 m)
Width 62" (1.57 m)
Height 75"(1.91 m)
Ground Clearance 9"(22.9 cm)
FuelCapacity 12 gal. (45.4 l)
Turning Radius 20'
Rear Payload Capacity 349 lbs. (158.3 kg)
Towing Capacity 3490 lbs. (1583 kg)
Person Capacity 2
Engine
Type Turbo Diesel m2DiCR
Turbo Peak Boost Pressure 1.61 bar (23.7 psi Absolute)
Cylinders 4 - 4 Stroke Compression Ignition
Displacement 2.5L / 152 Cu. In.
Bore and Stroke 35" x 40" (88.9 x 101.6 mm)
Power 62 HP @ 3200 rpm
Torque 144 ft. lbs. @ 1400-2200 rpm
© 2018 Mahindra Vehicle Sales and Service, Inc. All Rights Reserved. 77
