23 Maintenance Procedures
23.6 Check Differential Oil Levels & Leak Check
Before checking the front and rear differential oil levels, warm them
up. This is done by driving the ROXOR for 10-15 minutes.
Only perform when the ROXOR is on level ground or support. Do not
use an impact wrench to remove the differential oil level plugs, this
may damage the threads in the differentials resulting in a leak.
Maintenance Interval – Replace every 300 hours, 36 months, 9,000
miles (15,000 Km)
Fluid Spec. – GL-5 SAE 80W-90
Capacity – 1.6 Quarts (1.5 Liters)
1. Clean the differential oil level plugs and surrounding area.
a. Front Oil Level Plugs (see Figure 10)
b. Rear Oil Level Plugs (see Figure 11)
2. Remove the check/fill oil level plug and check whether oil is drip-
ping out.
3. If oil is not dripping out, oil level must be below the required
level.
4. Add specified oil to bring it to the level when it starts dripping
out.
5. Install and tighten the oil level plug.
Figure 10. Front Oil Level Plugs
© 2018 Mahindra Vehicle Sales and Service, Inc. All Rights Reserved. 59
