10 12FTHRAS THREADED HEIGHT ADJUSTER 4
11 12GMRA2L HEIGHT ADJUSTER (LH) 1
12 12GMRA2R HEIGHT ADJUSTER (RH) 1
13 12x3FSKS 1/2”x3” FINE SOCKET HEAD 12.9 24
14 190.000.545 PTO GUARD (EXTENDED OVAL) 1
15 199099 DIA 15-17mm INSERT 2
16 LF205H 6 SPLINE “L” BOX RATIO 1.92 2
17 LF205TH 6 SPLINE “T” BOX RATIO 1.92 2
18 5/8F 5/8” FINE NYLOC NUT 16
19 58x2FBZP 5/8”x2” FINE BOLT 16
20 60CSD 60mm STAR DRIVE 2
21 8-6-7-00161 3/8” VALVE BREATHER 5
22 8GMSTRP 8400 RM STRAP (3530mm) 1
23 EW29A 5/8” “D” SHACKLE 3
24 FWM12 M12 FLAT WASHER 8
25 FWM20 M20 FLAT WASHER 8
26 FWM8 M8 FLAT WASHER 4
27 GM2 STANDARD A-FRAME 1
28 GM84DRV 6 SPLINE STAR DRIVE 4
29 LS002 ANTI VIBRATION RUBBER 7
30 M12 M12 NYLOC NUT 16
31 M12x100BZP M12x100 BOLT 4
32 M12x30SZP M12x30 SET BOLT 4
33 M12x40BZP M12x40 BOLT 4
34 M12x50SZP M12x50 SET BOLT 2
35 M12x60BZP M12x60 BOLT 4
36 M20 M20 NYLOC NUT 2
37 M20HEX M20 PLAIN NUT 4
38 M20x120BZP M20x120 BOLT 2
39 M8x16SZP M8x16 SET BOLT 8
40 NT55A RUBBER COUPLING 4
41 RM-M20C ROLLER ADJUSTER CAP NUT 4
42 RMORA-1 OFFSET HEIGHT ADJUSTER (RH) 1
43 RMORA-2 OFFSET HEIGHT ADJUSTER (LH) 1
44 S15707 CAT 1/2 LINK PIN 2
45 3546 LINCH PIN DIA 9.5 2
46 849 GREASE NIPPLE M6 STR 4
47 SW58 5/8” SPRING WASHER 16
48 SWM12 M12 SPRING WASHER 4
49 T27A 6 SPLINE “T” BOX RATIO 1.92 1
50 T500810ENC12RW6 FIXED SLIP CLUTCH 1200 Nm 1
51 12T-BBS BLADE BACK SPACER 4
52 RM-RSN3 SHAFT COLLAR DIA 35 4
53 84RM-RD1 REAR DEFLECTOR 1
54 84RM-RD1H REAR DEFLECTOR 1
55 9TGT-CB GEARBOX COVER BRKT 2
56 GM6-4F GEARBOX REINF” 4
57 GM84-USC UNDERSIDE COVER 1
58 GM84-USCH UNDERSIDE COVER 1
59 RM-RSN2 ROLLER MOUNT 4
60 RM-RSN4 SCRAPER MOUNT 4
Item Part No Description Qty
8400GR Rollermower - Parts Listing
