6300GR and 8400GR Trailed Rollermower
Item Part No Description Qty
1 84RM-ADAX01 8400 AXLE 1
2 84RM-ADAX20 AXLE PIVOT PIN 2
3 84RM-ADDB01 8400 DRAWBAR 1
4 84RM-ADHT01 8400 HITCH 1
5 84RM-ADHT10 8400 COUPLING MOUNT 1
6 111070 DIA 50.5-54mm INSERT 2
7 199211 SQ 52-54mm INSERT (POL) 2
8 199269 DIA 57.5-61.5mm INSERT 2
9 1F 1” FINE NYLOC NUT 2
10 1x5FBZP 1”x5” FINE BOLT 2
11 26120012 DIA 650x320mm 2
12 AGI2RAM_B AGITATOR RAM 1
Item Part No Description Qty
13 BD16-2NH-50 50mm BALL HITCH 1
14 FW1 DIA 1” FLAT WASHER 2
15 M12 M12 NYLOC NUT 10
16 M12x100BZP M12x100 BOLT 2
17 M12x30SZP M12x30 SET BOLT 4
18 M12x35BZP M12x35 BOLT 2
19 M12x90BZP M12x90 BOLT 2
20 M16 M16 NYLOC NUT 4
21 M16x40SZP M16x40 SET BOLT 4
22 M20 M20 NYLOC NUT 2
23 M20x110BZP M20x110 BOLT 2
24 84RM-ADAX25 RAM SPACER BUSH 1
