12FT3PL Rollermower
Overview
Item Part No Description Qty
1 123RM-BGA 12000 3PL BODY ASSY 1
2 12RM-WGA-07 12000 WING (RH) 1
3 12W-PIN07 PIVOT PIN 4
4 T50-12W 12000 WING PTO SHAFT 2
5 17GM-WR4_B WING LIFT RAM 2
6 FW114 DIA 1 1/4” FLAT WASHER 4
7 FWM16 M16 FLAT WASHER 4
8 M16 M16 NYLOC NUT 2
9 M16x75BZP M16x75 BOLT 2
10 M20 M20 NYLOC NUT 4
11 M20x110BZP M20x110 BOLT 4
12 15501 CAT 0 PIN DIA 16x97mm 2
13 3546 LINCH PIN DIA 9.5 4
14 37 LINCH PIN DIA 6 2
15 4418 CAT 0 TOP LINK 2
16 849 GREASE NIPPLE M6 STR 4
17 V600910ENC12RW6 V60 FIXED SLIP CLUTCH 1
19 12RM-WGA-07H 12000 WING (LH) 1
20 951-BL 951 BLADE (Anti_Clk) 1
