Major 601SL - Spare Parts; 601 SL Grass Slasher

9
Item Part No Description Qty
1 SL61-BLDL 601 BLADE ASSY (STD) 1
2 SL61-BOD 601 SLASHER BODY 1
3 SL61-FG FRONT GUARD 1
4 SL65RG REAR GUARD 2
5 SLH16AS SKID SKID 601 2
6 LF205 6 SPLINE “L” BOX RATIO 1.47 (205.871) 1
7 5/8F 5/8” FINE NYLOC NUT 4
8 58x214FBZP 5/8”x2 1/4” FINE BOLT 4
9 EW29A 5/8” “D” SHACKLE 2
10 FWM8 M8 FLAT WASHER 4
11 FWM20 M20 Flat Washer 4
12 GM2 STANDARD A-FRAME 1
13 M12 M12 NYLOC NUT 13
14 M12x30SZP M12x30 SET BOLT 8
Item Part No Description Qty
15 M12x35BZP M12x35 BOLT 2
16 M12x40BZP M12x40 BOLT 1
17 M12x50BZP M12x50 BOLT 2
18 M20 M20 NYLOC NUT 2
19 M20x110BZP M20x110 BOLT 2
20 M8x16SZP M8x16 SET BOLT 4
21 NT20A PTO GUARD (RND) 1
22 S15707 CAT 1/2 LINK PIN 2
23 3546 LINCH PIN DIA 9.5 2
24 SL601 601 SL STRAP (1600mm) 1
25 SW58 5/8” SPRING WASHER 4
26 T40BO-1100 PTO Shaft 601 Slasher 1
27 12T-BBS BLADE BACK SPACER 2
28 8SM9/3 Spacer 8
Item Part No Description Qty
1 1/2F 1/2” Nyloc Nut 12
2 12x212FBZP 1/2”x2 1/2” FINE BOLT 4
3 8SM9/2 BLADE BACK (769 CTR) 2
4 9GT-USS Under sole skid
5 DF-BMP BLADE MOUNT 1
6 FW12 12” FLAT WASHER 4
Item Part No Description Qty
7 FWM20 M20 FLAT WASHER 4
8 M20 M20 NYLOC NUT 2
9 M20x60BZP M20x60 BOLT 2
10 NTSB10A SWING BLADE (Anti-Clk) 2
11 8SM9/3 Spacer 8
12 8SM9/4 Blade bushing (std) 4
601SL Grass Slasher Blade Assembly
Spare Parts - Slashers
601SL Grass Slasher
Use Genuine Parts
For best results you should always choose geniune parts for your machines. MAJOR spare parts are identical
to those used on our machines during assembly. They have been developed by our R&D department and tested
thoroughly to meet high quality standards. This also means that genuine MAJOR parts have the correct dimensions
and specications as the parts originally on your machine.
