Major 601SL - Jungle Buster (JB)

11
Item Part No Description Qty
1 16WT-BBA JB WING BLADE ASSY (Front Mt) 1
1 16WT-WBB JB WING BLADE ASSY (Rear Mt) 1
2 FS18-B01 FORESTRY 180 BODY 1
3 FS18-FG01 FRONT FLAP GUARD 8
4 FS18-FG04 FRONT FLAP BAR 2
5 FS18-FG05 REAR CHAIN BAR 1
6 FS18-FG06 FRONT CHAIN BAR 1
7 FS18-SK01 FS180 SKID 2
8 FS180-STRAP01 Jungle Buster CHAIN SLING 1
9 123RMA01 HEAVY A-FRAME 1
10 LF149/B LF149 GEARBOX 149.036.00 1
11 190000705 2 PIECE PTO GUARD 1
12 5/8F 5/8” FINE NYLOC NUT 6
13 58x214FBZP 5/8”x2 1/4” FINE BOLT 6
14 FS18-CH02 3/8” CHAIN STRAP 73
15 FWM8 M8 FLAT WASHER 4
Item Part No Description Qty
16 M12 M12 NYLOC NUT 16
17 M12x30SZP M12x30 SET BOLT 16
18 M16 M16 NYLOC NUT 8
19 M16x40SZP M16x40 SET BOLT 8
20 M20 M20 NYLOC NUT 6
21 M20x130BZP M20x130 BOLT 2
22 M6 M6 NYLOC NUT 8
23 M8x16 M8x16 SET BOLT 4
24 112 CAT 2 PIN DIA 28.5x159mm 2
25 1373 M8xDIA 9 U-BOLT 4
26 3546 LINCH PIN DIA 9.5 2
27 SW58 5/8” SPRING WASHER 6
28
T601210ENC12RW6
T60 FIXED SLIP CLUTCH 1
29 FS18-CG01 3/8” CHAIN MOUNT (REAR) 1
30 FS18-CG02 3/8” CHAIN MOUNT (FRONT) 1
31 FS18-FG03 GUARD MOUNT (FRONT) 2
Jungle Buster (JB)
Jungle Buster Blade Assembly
Item Part No. Description Qty
1 16WT-BM1 16WT BLADE MOUNT 1
2 16WT-USS UNDERSOLE PAN SKID 1
3 16WT-BB 16WT BODY BLADE 3
4 16WT-BBK 16WT BLADE BACK 2
5 1F 1" FINE NYLOC NUT 3
6 1x312FBZP 1"x3 1/2"FINE BOLT 3
7 58F 5/8" FINE NYLOC NUT 6
8 58x314FBZP 5/8"X3 1/4" FINE BOLT 6
9 D60253 DISC SPRING 60x25.4x3 3
10 FW1 DIA 1" FLAT WASHER 3
11 16WT-BBB BLADE BACK BUSH 3
12 16WT-BBS BLADE BACK SPACER 6
