Major 601SL - 605 SL Grass Slasher

10
Item Part No Description Qty
1 SL61-FG FRONT GUARD 1
2 SL65-BLD 605 BLADE ASSY (STD) 1
3 SL65-BOD 605 SLASHER BODY 1
4 SL65RG REAR GUARD 2
5 SLH16AS SKID 605 2
6 LF205
6 SPLINE “L” BOX RATIO 1.47
(205.871)
1
7 5/8F 5/8” FINE NYLOC NUT 4
8 58x214FBZP 5/8”x2 1/4” FINE BOLT 4
9 EW29A 5/8” “D” SHACKLE 3
10 FWM8 M8 FLAT WASHER 4
11 FWM20 M20 Flat Washer 4
12 GM2 STANDARD A-FRAME 1
13 M12 M12 NYLOC NUT 13
Item Part No Description Qty
14 M12x30SZP M12x30 SET BOLT 10
15 M12x35BZP M12x35 BOLT 3
16 M20 M20 NYLOC NUT 2
17 M20x110BZP M20x110 BOLT 2
18 M8x16SZP M8x16 SET BOLT 4
19 NT20A PTO GUARD (RND) 1
20 S15707 CAT 1/2 LINK PIN 2
21 3546 LINCH PIN DIA 9.5 2
22 SL605 605 SL STRAP (3850mm) 1
23 SW58 5/8” SPRING WASHER 4
24 T50BO-1100 PTO Shaft 605 Slasher 1
25 8SM9/3 Spacer 8
605SL Grass Slasher
605SL Grass Slasher Blade Assembly
