Major 601SL - Gearboxes; LF149;B Gearbox Breakdown

15
Item Part No Description Qty
1 0.149.0301.00 CASING 1
2 8.0.9.00129 BEARING 30307 2
3 8.7.1.00315 (358010) DOUBLE LIP SEAL 35X80X10 1
4 0.149.2001.00 SHAFT 1”3/8 Z6 1
5 85200030 SNAP RING 80 UNI7437 2
6 0.267.7500.00 SHIM 79.9 2
7 8.4.7.01111 COTTER PIN B4X55 1
8 8.0.9.00128 BEARING 30308 1
9 0.132.7106.00 NUT M30X1.5 1
10 0.149.3000.00 SHAFT ASA DP 8/16 1
11 0.139.7100.00 PROTECTIVE WASHER 1
12 8.7.1.01107 DOUBLE LIP SEAL 50X90X10 1
Item Part No Description Qty
13 0.149.5000.00 GEAR Z20 M6.25 2
14 8.0.9.00469 BEARING 30210 1
15 0.244.7500.00 SHIM KIT 40.3x51.5 1
16 0.259.7525.00 SHIM 35.3x2.5 1
17 8.7.0.00790 CAP 80X10 1
18 8.1.1.00326 BOLTM8X16 8,8 4
19 0.149.710.000 PLUG 3/8 GAS 1
20 0.149.1300.00 COVER 1
21 0.139.7101.00 BLANK WASHER 1
22 8.2.2.00555 Castle Nut M30X2 PR80 1
251 0.139.7000.00 BUSH 1
252 8.4.7.00146 COTTER PIN B6X60 1
LF149/B (9.149.036.00) Gearbox Breakdown
Gearboxes
