609SL Grass Slasher BEFORE HR16350
Item Part No. Description Qty
1 SL609-BGA SLASHER BODY WELDMENT 1
2 SL609-LMW SLASHER LINKAGE WELDMENT 1
3 SL609-LMW-H HANDED LINKAGE WELDMENT 1
4 SL69-BLD 609 BLADE ASSY (STD) 1
5 SL69-SKD SKID (OFFSET) 2
6 3546 LINCH PIN DIA 9.5 2
7 5/8F 5/8" FINE NYLOC NUT 4
8 58x214FBZP 5/8"x2 1/4" FINE BOLT 4
9 EW29A 5/8" 'D' SHACKLE 3
10 FWM12 M12 FLAT WASHER 18
11 FWM20 M20 FLAT WASHER 4
12 GM2 STANDARD A-FRAME 1
13 M12 M12 NYLOC NUT 26
14 M12x120BZP M12x120 BOLT 4
15 M12x30SZP M12x30 SET BOLT 8
16 M12x35BZP M12x35 BOLT 14
17 M20 M20 NYLOC NUT 2
18 M20x110BZP M20x110 BOLT 2
19 MJ40L (347800) 6 SPLINE 'L' BOX RATIO 1.47 1
20 NT20A PTO GUARD (RND) 1
21 S15707 CAT 1/2 LINK PIN 2
22 SL605 605 SL STRAP (3850mm) 1
23 SW58 5/8" SPRING WASHER 4
24 T501160CEC12B02 T50 SHEAR BOLT 1
25 SL609-B003 GEARBOX UNDERPLATE 1
