MAKERBOT REPLICATOR 2 DIAGRAM
8
10
2
11
3
7
5
6
4
9
1
[1] GANTRY SYSTEM
[2] LCD PANEL
[3] KEY PAD
[4] THREADED Z-AXIS ROD
[5] BUILD PLATE
[6] BUILD PLATFORM
[7] FILAMENT GUIDE TUBE
[8] EXTRUDER CABLE
[9] EXTRUDER
[10] FILAMENT SPOOL
[11] SPOOL HOLDER
®
SETTING UP YOUR MAKERBOT REPLICATOR 2 DESKTOP 3D PRINTER
