Operation
•
Entering a program
•
Press
p
P appears on the display.
•
Enter program number
0 1
...
9 9.
The number will be shown on the display
J
•
If measurement is shown on the display
O
the program is reserved.
•
Enter a measurement or advance with the
hand-wheel
Q
.
•
g
Store the dimension next program step
appears.
•
Enter the next dimension.
•
g
Store the dimension
• p
+
s
Escape the program mode.
Eject function program
•
The eject function can be added each time a
measurement is entered and ejects before
advancing to the next measurement.
•
Enter the next dimension.
• Press
z
LED "E" appears.
•
g
Store the dimension.
Example of a program eject function
•
p
0 8
program 08
• c c
delete previous program
•
2 7
step 1 on 27,0 cm
• z g
eject
• 1 9
step 2 on 19,0 cm
•
p s
escape the program mode
How the example works
•
p
0 8
start program 08
• S
proceeds to position
•
Insert paper
•
Release cut 1
•
Release cut 2
•
Paper is ejected
•
p s
escape the program mode
