5 ENGLISH
Use an air hose as large and as short as possible to
with an internal diameter of over 6.5 mm and a length
of less than 20 m is recommended when the interval
between each stapling is 0.5 seconds.
Air supply hoses shall have a minimum working pres-
sure rating of 1.03 MPa (10.3 bar) or 150 percent of the
maximum pressure produced in the system whichever
is higher.
Lubrication
for every 50 staples.
tool oil by placing 2 (two) or 3 (three) drops into the air
times after pneumatic tool oil is introduced.
1
1. Pneumatic tool oil
FUNCTIONAL
DESCRIPTION
CAUTION: Before adjusting or checking
function on the tool, always return the trigger and
disconnect the air hose from the tool.
Adjusting depth of stapling
1
B
A
1.
If staples cannot be driven deep enough even when the
air pressure.
when the tool is used with lower air pressure and the
Hook
CAUTION: Never hook the tool at high loca-
tion or on potentially unstable surface.
CAUTION: Do not hang the hook from the
waist belt.
1
1. Hook
