5 TIGHTENING TORQUE SPECIFICATIONS

Parts to fasten

Fastener

Q'ty

Tightening

torque

(N∙m)

Adhesion

Housing set ↔ Guide plate L

M5x12 H. L. socket head bolt

4.0 - 6.0

Housing set ↔ Front handle

5x20 Tapping screw

1.5 - 2.0

Sprocket cover ass’y ↔ Nut cover

4x12 Tapping screw

0.8 - 1.0

* Apply the specified adhesive to M5x12 H. L. socket head (4 LUBRICANT AND ADHESIVE APPLICATION).

For screws except above, see Repair basic manual, Chapter 2.

Makita DUC256PG2 Repair Manual
