Makita LS1018L Technical Information

P 3/ 45
Repair
[2] LUBRICATION (cont.)
Fig. 2
Support arm section
Support arm
90 degree block
Friction ring
Working table
Locking rod
Fig. 3
Up blade guard section
Up blade guard
Up blade guard bracket
Pin cap
Sealing ring
Pin C
Location tube
Torsion spring
Connection shaft

Makita LS1018L Specifications

General

Input power	1430 W
Power source	AC
Blade bore	30 mm
Blade diameter	260 mm
Dust bag included	JM23100501
Saw blade included	Yes
Idle speed (max)	4300 RPM

Weight and Dimensions

Depth	536 mm
Width	825 mm
Height	633 mm
Weight	19800 g
