64
03/09
125 - 160 cc
Blog
Blog
Blog
Blog
Blog
FIL
TER BO
X UNIT
•
Unhook the clamp (A).
•
Disconnect the tube (C ) "IDLE" valve- filter box sleeve.
•
Remove the clamps (B).
•
Disconnect the vapour recovery tube (C).
•
Cut the ties (E).
•
Disconnect the connector (F) (Inlet air temperature sensor)
•
Loosen the clamps (G).
F
. 147
F
.
148
C
E
F
A
G
E
The ties that have been cut in order to remove various components must be replaced with identical ones, and placed in the original position.
C
1
B
63
65
