NOTES FOR EASY CONSULTATION
ABBREVIATIONS
EDITING SYMBOLS:
• Symbols have been provided for quick and easy reference, identifying situations requiring utmost attention or providing practical suggestions or simple information.
• These symbols may appear next to a text (in which case they refer solely to the text itself), next to a figure (in which case they refer to the topic illustrated in the figure and
to the relative text), or at the top of the page (in which case they refer to all the topics dealt with in the page).
NOTE - The meaning of the symbols should be duly memorised as their scope is to avoid having to repeat basic technical concepts or safety recommendations.
Cs Torque wrench setting
D Nut
Dx Right
F Picture
G Gasket
P Page
R Washer
Sx Left
T Ta bl e
V Screw
TECHNICAL DICTIONARY
V = (DC) Direct current (battery supply)
V ~ (AC) Alternating current (flywheel supply)
A : Ampere Unit of measurement of the electrical current
W : Watt Unit of measurement of the electrical power (product of Volts and Amperes; A x V = W)
ΩΩ
ΩΩ
Ω : OHM Unit of measurement of the electrical resistance
< Lower
≤≤
≤≤
≤ Lower or equal
> Higher
≥≥
≥≥
≥ Higher or equal
bar Unit of measurement of pressure
N * m Newton/metre Unit of measurement of the tightening torque
