Malmet WDS1 - Page 39

Bedpan / Urinal Bottle and Utensil / Bowl Washer Disinfector (WDS)
Operation, Maintenance and Installation Manual
Issue 16 Page 38 August 22
Item
Description
P/N
Qty
Item
Description
P/N
Qty
1
Water tank assembly (for 1 Ph device)
Water tank assembly (for 3 Ph device)
92-4019SP
92-4056SP
1
32
Temperature Probe Duplex
91-3130SP
1
2
Spray line top assembly
92-4037SP
1
33
Conductivity sensor
92-3007SP
1
3
Temperature probe & ¼” brass olive
81-2405SP
1
34
Detergent flow sensor
92-3011SP
1
4
Spray line bottom assembly
92-4038SP
1
35
Water tank screen assembly
92-4042SP
1
5
Door top switch J10 assembly
92-4079SP
1
36
Harness (Hot tank sensor)
82-2261SP
1
6
Door bottom switch assembly - J11
*Micro Switch in this position must be ordered as this assembly.
92-4080SP
1
37
Spray nozzle Cool down WL1 1/4
120°
92-3047SP
2
7
Pump drain line assembly
92-4045SP
1
38
Spray nozzle Top WL1/4 90°
92-3046SP
4
8
Wash Pump assembly
92-4044SP
1
39
Spray nozzle Bottom WL1/2 60°
92-3048SP
4
9
Spray line cool down assembly
92-4040SP
1
40
Spray nozzle Urine WL1/4 90°
92-3046SP
4
10
Bowl rack sensor sw assembly
92-4087SP
1
41
Spray nozzle Tip WL1/2 120°
92-3049SP
2
11
Heating Element 4.5kw
91-3040SP
1
42
Flush nozzle Rotary
92-3063SP
2
12
Steam generator assembly
92-4022SP
1
43
Magnet rack position sensor
assembly
92-4055SP
2
13
Cold water in solenoid 2 way
92-3012SP
1
44
Blockage Sensor
92-4074SP
1
14
Hot water in solenoid 1 way
81-2099SP
1
45
Pan rack sensor switch assembly
(inside door)
92-4089SP
1
15
Fill level probe assembly
91-3114SP
1
46
Micro switch
82-2361SP
2
16
Solenoid valve 1” BSP
92-3233SP
1
47
Pump drain solenoid valve ½”
92-3014SP
1
17
Spray solenoid 4 way
92-3013SP
1
48
O/T switch 115°C (S/G element)
91-3059SP
1
18
P trap
91-2029SP
1
49
Fill solenoid (steam generator)
91-3068SP
1
S trap
91-2028SP
1
50
O/T switch 100°C (W/T element)
92-3153SP
1
19
Control module
92-3005SP
1
51
Detergent pump assembly
92-4058SP
1
20
Processor module
92-3006SP
1
52
Gasket door seal
92-3113SP
1
21
Control display assembly
92-4070SP
1
53
Actuator (Door open/close)
91-4086SP
1
22
Heater switch module
92-3004SP
1
54
Axle bar assembly (Door)
92-4036SP
1
23
Heating Element 4.5kw (for 1ph
device)
91-3040SP
1
55
RFI filter 1ph
92-3144SP
1
24
Heating Element 7.2kw (for 3ph
device)
92-3128SP
1
56
Battery
92-3200SP
1
25
Transformer assembly at rear
92-4049SP
1
57
Door hinge assembly
92-4142SP
2
26
Contactor 7.5kw (for 3ph device)
92-3127SP
2
58
Harness-Conductivity sensor PCB
92-3503SP
1
27
Detergent pump/line assembly
92-4046SP
1
59
Rack - Bedpan
92-3030SP
1
28
Detergent bottle line assembly
92-4047SP
1
60
Rack - Bowl/Utensil
92-3031SP
1
29
Load cell mount assembly
92-4076SP
1
61
Bottle Holder
92-4014SP
1
30
5 level probe assembly (water tank)
92-4075SP
1
62
Transformer Fuse 5A (Time Delay)
92-3228SP
1
31
HW in line assembly
92-4041SP
1
63
EMI Filter 3ph
92-3244SP
1
